- It is a 2WD tractor that comes in 60 horsepower.
- An economical tractor due to minimal consumption of fuel.
- Environmentally friendly due to less emission of smoke.
- Minimal operational costs.
- High PTO power ensures smooth working with threshers.
- A three-cylinder diesel engine with 8 forward and 2 reverse gears.
- Features a spring suspension seat, along with check chains and chain stabilizer.
- Functions up to 18 hours without heating up.
- Sliding spur transmission.
- Oil-immersed multi-disc mechanical brakes.
- Manual steering.
| Engine Power at 2,250 rpm> | 60 (B.S) hp |
| Torque at 1,600 rpm | 212 Nm |
| PTO Power at Rated | 48hp |
| Engine Speed | |
| *Certified at BS AU 141a 1971 | **Manufacturer’s Estimate |
| Voltage | 12V, Negative Earth |
| Battery | 110 Ah |
| Starter | 2.2 kW |
| Alternator | 32 Amp |
| Type | Sliding Spur |
| Number of Gears | 8 Forward, 2 Reverse |
| Road Speed at 2,250 | Engine RPM with 14.9/13-28 rear tyres |
| Gear | Speed (km/hr) |
| Forward 1 (First Low) | 2.7 |
| Forward 2 | 3.9 |
| Forward 3 | 5.3 |
| Forward 4 | 7.2 |
| Forward 5 (First High) | 10.6 |
| Forward 6 | 15.6 |
| Forward 7 | 21.3 |
| Forward 8 | 28.7 |
| Reverse 1 (Low) | 3.6 |
| Reverse 2 (High) | 14.5 |
| Functions | Draft Control, Position Control Response Control, Constant Pumping |
| Pump Type | Reciprocating, Ferguson Pump |
| Oil Flow | 16 ltr/mix |
| Pressure | 21.0 Mpa at normal operating temperature |
| Links Horizontal | |
| Lower Links | With Cat, I & II Interchangeable Balls |
| Brake Type | Oil immersed, Multi-disc |
| Brake Actuation | Mechanical |
| Axle Type | Straddle with apicyclic redution |
| Parking Brake | Hand Lever Operated |
| Front | 7.50 - 16 (6PR) |
| Rear | 14.9 / 13 - 28 (6PR) |
| Type | Dual |
| Diameter | 305 x 254 mm |
| Type | Box Section, Adjustable |
| Type | Manual |
| Front Axle | 1,245 - 1,854 mm |
| Rear Axle | 1,423 - 2,134 mm |
| Make / Type | Diesel T 3.1524 |
| No. of Cylinders | 3 |
| Rear Axle | 1,423 - 2,134 mm |
| Make / Type | Diesel T 3.1524 |
| No. of Cylinders | 3 |
| Injection | Direct |
| Bore | 91.4mm |
| Stroke | 127.0mm |
| Capacity (litres) | 2.5 L |
| Compression Ratio | 15.5:1 |
| Aspiration | Turbo |
| Starting Aid | Thermostart |
| Throttle Control | Hand and Feet |
| Cooling | Water |
| Air Cleaner Type | Oil Bath |
| Air Pre-Cleaner | Over Bonnet, Air Swirl |
| Fuel Filter | Dual, High Capacity |
| Exhaust | Vertical |
| Oil Cooler | Air Cooler, Fin Type |
| Type | Live |
| Engine Speed at 540 pto rpm | 1,789 rpm |
| Shaft Diameter | 35mm |
| No. of Splines | 6 |
| Guages | Technometer, Hourmeter, Fuel Level, Battery Condition & Water Temperature |
| Warning Lights | Direction Indicators, Battery Charge, Headlight Main Beam, Low Engine Oil Pressure & Brake Lights |
| Gross Weight | 1,900 kg |
| Wheel Base | 1,892 mm |
| Overall Length | 3,260 mm |
| Overall Width (Min) | 1,890 mm |
| Over Exhaust | 2,220 mm |
| Over Steering Wheel | 1,490 mm |
| With Brakes | 5,840 mm |
| Without Brakes | 6,580 mm |
| Under Gear Box | 400 mm |
| Fuel Tank | 47.0L |
| Engine Pump | 6.8L |
| Cooling System | 10.2L |
| Hydraulic System | 36.0L |
| Steering Box | 0.9L |
| Oil Bath Air-Cleaner | 0.5L |
