A swinging drawbar hauls large loads around. Its one end is attached to a tractor. Drawbars allow easier turning. It is a solid coupling device which ensures that a tractor can haul heavy loads with ease. It maximises flexibility to loads and is especially useful when driving through turns. Our swinging drawbar is a safe device that produces a slightly lateral movement in order to ensure easier turning of towing devices, parallel to a tractor’s motion. It decreases rigidity and allows for a fluid turning. This decreases chances of any tipping issues.
Swinging Drawbar
Specifications
Swinging Drawbar.
Length: 30 in.
Thickness: 1 in.
Width: 1-7/8 in.
Pin holes on tractor end: 1 in.
Pin holes on attachment end: 3/4 in.
Lateral movement.
Hauling device more flexible when turning.
